ARGES Copper Sensor

The ARGES Copper Sensor by Keynes Controls is a submersible sensor designed to simplify how you capture water quality measurement parameters. It feeds directly into any platform that supports real-time reporting and data logging operations.

The Copper Sensor by Keynes Controls works as a stand-alone unit, or as part of a multi-parameter sensor array. Each ARGES chemical sensor can be combined with other Keynes Controls sensors   using the same common user interface.

Copper toxicity is highest at pH levels between 6 and 8 and is heavily influenced by dissolved organic matter (DOM), which binds with copper to reduce the concentration of toxic free ions.

Why test for copper in water sources

Contaminated with dissolved copper water source

Measuring copper is critically important in applications such as wastewater, where treatment plants are required to provide a laboratory measurement of copper concentration.

Copper levels higher than around 1.3 mg/l are a good indicator of a polluted water source. Common sources of elevated copper in water include corrosion of copper pipes and plumbing fittings, industrial discharge, mining runoff, and the manufacturing of electrical components and alloys. Accurate, real-time monitoring is essential to assess water quality, protect public health, and meet regulatory requirements.

Copper Sensor
CE Logo

Measurement Integrity

All of the ARGES sensor range has the serial numbers and the last calibration date stored internally. The user can access this information for reporting purposes. The sensors can be redeployed at any time with the calibration and serial number records are retained in the sensor.

ISOLATION

The sensor element of the Copper Sensor is isolated when not required for any measurements. This prevents contamination of the sensor element and maintains the long active life of the device.

When no measurement is being made the sensor is in low power mode.

Dissolved Copper

Copper often exhibits non-conservative behavior at the freshwater-saltwater interface, where rapid pH increases and the formation of amorphous iron flocs cause a significant portion of dissolved copper to precipitate and settle into sediment

Agricultural & Industrial Runoff

Major contributors of dissolved copper include domestic wastewater (the largest anthropogenic source), acid mine drainage (releasing copper from historical mining operations), and atmospheric deposition from transport and industry.

Sources of Copper in water

Copper primarily enters drinking water through the corrosion of copper pipes and plumbing fixtures within buildings, rather than from the water supply itself.

Natural Sources

The natural formation of dissolved copper and other metals in rivers is primarily driven by acid rock drainage, a geochemical process where sulfur-bearing minerals weather and oxidize naturally. When exposed to water and oxygen the mineral can break down to produce sulfuric acid. The acidic water then leaches metals like copper, iron, zinc, and nickel directly out of the surrounding bedrock and into nearby river systems.

UK Legal Limit for copper in drinking water:

The legal limit for copper in drinking water is 2 mg/L / 2 ppm. The ARGES Copper sensor can report this level.

Dissolved Copper Pollution
Dissolved Copper water Pollution

Product Features



TYPE RANGE (Typical levels)
Solid State ISE sensor.
Concentration Range: 0.006–64,000 ppm
                  Resolution: 0.01 - parts per million
                   Accuracy: +/- 10 % range reading - accurate solid state sensor
Operation
Stand-alone and SONDE Multi-parameter
Calibration User calibrated - recommended before each deployment
Interference IONS Mercury, Silver, Sulphide
pH Range 2-7
Protection No membrane replacements
In-built Digital Communications SDI12 / RS485 / MODBUS
Settling Time 10-60 Seconds after submergence
Operating Temperature 5 – 50°C
SI Units
ppm, mg/l, mol/dm³, °C -- temperature compensated measurements
Sensor Isolation: Reference cells isolated between measurements
Interference IONS Hg, Ag, S²⁻
Potential Drift 2mV per Day



Calibration Summary

The ARGES Copper Sensor by Keynes Controls is typically calibrated at 2 points. The overall accuracy of the sensor will depend upon how well the ARGES Copper sensor has calibrated.  The sensor by default uses a 2 point calibration procedure.

The sensor requires a high concentration and low concentration calibration points.  For most river water analysis Keynes uses 50 ppm for the high level, and 5 ppm for the low calibration point. A zero point using distilled water should not be used with this sensor.

The SONDE Turbidity Calibration and Q-LOG software by Keynes Controls

For best results the calibration should be done at the temperature that the sensor will be deployed. Calibration is undertaken in collaboration with a pH and temperature sensor.

When measuring concentrations of metals and minerals in water:
1 milligram per liter (mg/L) = 1 part per million (ppm)
1 microgram per liter (ug/L) = 1 part per billion (ppb) and 1 ppm = 1,000 ppb

Storage and Handling

When not in use the ARGES Copper Sensor By Keynes Controls is solid state and can be stored dry for a  long period without any effect.

Storage temperature range : 2 - 60 Degrees Celsius.

Further Information:

Guidelines for drinking-water quality,  WHO 1996.

Natural level in ground water is usually below 0.2 mg/L.

Higher natural levels are found in strata rich in humic substances or iron or in forests.

Surface water may contain up to 12 mg/L in drinking water as a result of disinfection with chloramines

Product Specifications

Network Type ENVIRONMENTAL CHARACTERISTICS
SDI12  1.4 Temperature Range: 0 to 60 Degree Celsius
RS485 Ambient Range: 0 - 50    Degree Celsius
MODBUS Over RS485 - 16 and 32 Bit Registers Water Temperature:     -2 to 60  Degree Celsius
Maximum Depth: 10 m
Process Electrodes:    Solid State - No reagents
Material: PVC / Stainless Steel PHYSICAL DIMENSIONS
Interference ION: K+   Na+ Length x Diameter: 22 x  220 mm
Weight: 97 g
Settling Time
Typically 20 Seconds after deployment
Maximum Depth : 10 m
Measurement Order User Defined
Built-in Network Types:
Excitation Galvanic SDI12 / RS485 / MODBUS over 485
Housing 316 Stainless Steel and PVC
Sensor Connector Gold Plated Power Requirement
Voltage Range: 10-18 V DC
Data Output ppm, mg/l, mol/dm³,  Deg °C Standby Current: 0.8  mA Typical
Temp Compensated ppm, mg/l, mol/dm³ Reading: 6 mA Typical


Please Note: The Copper Sensor is pre-calibrated at the factory.

Supported Commands

Most Used Commands - SDI12 v1.4 supported SI unit assignment automatically.

Description Command      Instrument Response
Start measurement aM! a05\r\n    where 05 = time delay before measurement sent
Send ID al! a14KEYNESCOISO000014\r\n    Part description assigned by Keynes
Address Query ?! Where a = ID number - 0 - 9 (standard) / (a..z) Enhanced SDI-12
0 - 9 / a - z for RS485
Change Address aAb!  where a = Initial address  and  b = Final address
Start Measurement aM! Make a measurement  - a = address of sensor
Example   1M! starts a measurement for sensor with ID=1
Set Output Variables XCSTR0 Sets the parameter order for measurements sent from the sensor - default AMGE
Read Serial Number aXSN! Instrument Response    a+Serial-number
Calibration Date aXCD! Instrument Response     a+date
- - -
User Assigned Parameters
First point raw sensor reading in millivolts   Sensor reading at 1st calibration point
First calibration point ppm    First calibration solution concentration in ppm
Second raw sensor reading in millivolts   Sensor reading at 2nd calibration point
Second calibration point ppm   Second calibration solution concentration in ppm
Drift   0.75 mV / Day 0 - 15 °  (Typical)
Calibration temperature Temperature of the calibration solution
SDI12 V1.14  (Default factory settings)



Commonly used with: pH, CDOM/fDOM, Conductivity

The Copper Sensor by Keynes Controls monitors the levels of Copper in water. The ARGES Copper Sensor by Keynes Controls readings can be affected by changes in temperature and salinity. This sensor is frequently paired with: pH, Turbidity, Typtophan, Conductivity sensors and other temperature sensors crafted and produced by Keynes Controls.

Submersible pH Sensor = The Intelligent Submersible pH Sensor by Keynes Controls, is a high performance submersible sensor that has been designed to simplify the acquisition of water quality measurement parameters, Copper concentration and toxicity increases as pH increases, although less copper is required to produce toxic effects at lower pH.

Temperature Effects on Dissolved Copper in water.

The Toxicity of dissolved copper increases as temperature increases,

Built-in Communication Options

The ARGES Copper Sensor by Keynes Controls supports SDI12, RS485 and MODBUS digital communications as standard enabling it to be directly connected to Data Logger for remote web based reporting, onto Wi-Fi and Local Area Networks using the RS485 option. The MODBUS and RS485 option are often used to connect sensors to a PLC Controller and Display Units,. The MODBUS protocol enables the sensors to be used directly by most SCADA applications software.

COPPER

Optional USB Interfaces

Keynes Controls manufactures a range of accessories that can be used to connect the ARGES range of sensors to a Windows computer system and enable the sensors to be used in Laboratory applications, multi-parameter instruments and calibration operations.

The optional USB media converters can be used to connect a multi-parameter instrument to a PC.

USB-SDI12 AG1 Media Converter by Keynes Controls

Q-LOG Software

The ARGES Copper Sensor by Keynes Controls is integrated into the Keynes Controls Q-LOG software.

Our Q-LOG software runs on the widely recognised Windows Operating system, you have the ability to calibrate, adjust instrument network address, and effortlessly display measurements on a series of panel meters and charts. Conveniently store results in text based files for quick analysis in spreadsheets.



MODBUS Operations

ALL of the ARGES range of chemical sensors support MODBUS network operations The sensors act as a slave unit only and can communicate to suitable controllers and SCADA systems that support the MODBUS Protocol. The sensors support 16 and 32 bit registers.   .

The ARGES sensors can be connected to a PC based system using the optional USB-485-Pro media converter. This device can power the chemical sensor and supports the correct timing protocols for data transmission for MODBUS and standard RS485 network communications
