Get the most advanced DIN Rail Mounted Vibrating Wire technology from Keynes Controls. The intelligent VibWire-301 has an interface that features SDI12 and RS485 communications, independent 4-20 mA loop and 0-2V DC Output - frequency temperature. MODBUS over RS485.
The VibWire-301 has been designed to offer fast installation and an optional USB Interface and Terminal Port Menu System.
The VibWire-301 Product Specifications and Technical Data Sheet is available below and provides all of the information you will need. However, please feel free to contact us directly for more information.
Product Specification:
- DIN rail mounted Vibrating Wire Interface for fast installation
- SDI12 Communications
- RS485 Communications
- MODBUS
- Independent 4-20 mA Loop Frequency Temperature
- Independent 0 - 2 V DC Output - Frequency Temperature
- Free Applications Software
- Optional USB Interface
- Terminal Port Menu System
The image above shows the speaker unit on/off switch and terminal port connection. A good quality sensor will give a regular pure tone.
The image above shows the pin-out for the sensor and network output ports.
VibWire-301 Digital Communications
RS485 Communications
The VibWire-301 instruments can be connected to a Wi-Fi network using a RS485 to Wi-Fi Gateway.
Application Software
Free issue Q-LOG Windows Application Software can be used for Configuration, Test Measurements, Results display in Charts and Panel Meters, Data storage in CSV file format for easy analysis
Local Area Network Connection
The VibWire-301 can be easily connection to a Local Area Network (LAN) using a RS485 to Ethernet LAN Converter. The Q-LOG software supports a Virtual COMM port and this feature enables a Windows PC to talk to the instruments across a LAN
Vibrating Wire Interface Installation Accessories
Keynes Controls Offer a range of accessories to simplify the installation and testing of the VibWire-301 interface.
Optional USB Interfaces
Keynes Controls manufactures a range of USB media converters that can be used to connect the VibWire-108 to a Windows PC. The media converters isolate the
At Keynes Controls we used the following sensor types: Piezometer, Arc weldable Strain gauge, Displacement, Earth Pressure cell, Inclinometer, Rebar Strain, Dynamic vibrating wire, Uplift pressure, vibrating wire DIN Rail, VW DIN rail, Vibrating wire 4-20 mA, current loop VW, vibrating wire analogue, vibrating wire analog, 4-20 mA loop vibrating wire, analogue vibrating wire, VW PLC Modbus, VW MODBUS, vibrating wire MODBUS, MODBUS vibrating wire, 1 channel VW interface, concurrent measurement, high speed vibrating wire, single channel vibrating wire, Digits
Additional Material
Instrument Terminal Port Menu System - Software Communication Settings - Menu Operation
Instrument Terminal Port Menu System - Software Communication Settings - Menu Operation
VibWire-301 Vibrating Wire Interface - QLOG Configuration Windows Software - Training Video
